    The Gainscha GI‑2408T is a robust 4‑inch industrial thermal printer designed for high‑volume barcode label printing in settings like manufacturing, warehousing, and distribution. It supports both thermal transfer and direct thermal modes and can integrate with barcode scanners or keyboards via USB Host.

    • Resolution: 8 dots/mm(203DPI)
    • Printing Method: Thermal Transfer & Direct Thermal
    • Max. Print Speed: 203mm(8″)/second
    • Max. Print Width: 104 mm (4.09″)
    • Max. Print Length: 15,000mm (600″)
    • Interface: USB & Ethernet (Optional Bluetooth & WIFI)

    Download Brochure

    Send Enquiry
    Category Tags ,

    Introducing the Gainscha GI‑2408T Industrial Barcode Label Printer

    The Gainscha GI‑2408T is a robust 4‑inch industrial thermal printer designed for high‑volume barcode label printing in settings like manufacturing, warehousing, and distribution. It supports both thermal transfer and direct thermal modes and can integrate with barcode scanners or keyboards via USB Host.

    • High-speed printing at up to 203 mm (8″) per second.

    • Resolution: 8 dots/mm (≈203 DPI) for clear, scannable labels.

    • CPU: 400 MHz 32‑bit ARM9 with 128 MB SDRAM and 128 MB Flash memory.

    • Firmware Emulation: Pre‑installed support for TSPL, EPL, EPL2, ZPL/ZPL II, and DPL, enabling compatibility with many existing systems.

    • Media & Ribbon Support: Handles media width up to 120 mm (≈4.72″), ribbon width up to 115 mm (≈4.5″), and ribbon rolls up to 450 m (1″ core).

    • Interfaces: USB 2.0 high‑speed, USB Host (for scanner/keyboard), RS‑232, Ethernet 10/100 Mbps; factory‑option Bluetooth 4.2 and Wi‑Fi.

    • Sensors & Options: Includes gap and black‑mark sensors, head‑open sensor, ribbon‑end and label‑end sensors. Optional cutter and peeler available.

    • User Interface: Simple controls—power switch, Feed & Pause buttons, and four LEDs indicating status. (The Empower variant adds a 4.3″ TFT touch screen.)

    Model GI-2408T; GI-3406T
    Level Standard
    Resolution GI-2408T: 8 dots/mm (203DPI)
    GI-3406T: 12 dots/mm (300DPI)
    Printing Method Thermal Transfer & Direct Thermal
    Max. Print Speed GI-2408T: 203mm(8″)/second
    GI-3406T: 152mm(6″)/second
    Max. Print Width GI-2408T: 104 mm (4.09″)
    GI-3406T: 108mm (4.25″)
    Max. Print Length GI-2408T PLUS: 15,000mm (600″)
    GI-3406T PLUS: 6800mm (267.7″)
    CPU 400 MHz, 32 bits, ARM9
    Memory RAM 128 MB SDRAM
    Memory ROM 128 MB Flash
    Interface • USB 2.0 High Speed 480Mbps
    • USB Host 2.0, for scanner or PC keyboard
    • RS-232
    • Internal Ethernet 10/100Mbps
    • Internal Bluetooth 4.2 (factory option)
    • Internal Wi-Fi (factory option)
    Real Time Clock Standard
    Buzzer Standard
    Dealer Options • Guillotine cutter
    • Peeler
    Sensors • Gap transmissive sensor (position adjustable)
    • Black mark reflective sensor (position adjustable)
    • Head open sensor
    • Ribbon end sensor
    • Label end sensor
    Power Internal universal switching power supply, Input: AC 100-240V，1.5A，50-60Hz， Output: DC 24V，5A，120W
    User Interface • 1 power switch
    • 2 buttons (Feed & Pause)
    • 4 LEDs (Online, Error, Ribbon, Communication status)
    Internal Fonts • 8 alpha-numeric bitmap fonts
    • True type font engine (need to download scalable font file)
    1D Barcode Code 11，Code 39，Code 93，Code 128 (subsets A，B，C)，UPC-A，UPC-E，UCC-128，Codabar，EAN/JAN-8，EAN/JAN-13，Interleaved 2 of 5，ITF14，MSI Pleassy, PostCode, Telepen
    2D Barcode QR Code, Micro QR Code，PDF417，Micro PDF417，MaxiCode，Aztec Code, Data Matrix
    Rotation Font and barcode support 0，90，180，270 degree
    Printer Language Compatible to TSPL，EPL，EPL 2，ZPL，ZPL II，DPL
    Ribbon 450 meters long, max. OD 105 mm, 1″ core (ink coated outside)
    Ribbon Width Max.115 mm (4.5″)
    Media Type Continuous, die-cut, black mark, fan-fold (outside wound)
    Media Width 20 ~ 120 mm (0.78″~ 4.72″)
    Media Thickness 0.06 ~ 0.254 mm (2.36~10 mil)
    Media Core Diameter 25.4 ~76.2 mm (1″~ 3″)
    Label Roll Capacity 203mm (8″) OD
    Physical Dimension 425mm(L) x 255mm(W) x 265mm(H)
    Net Weight 9.65kg
    Enclosure Die-cast based print mechanism and metal cover with large clear media view window
    Safety Regulation FCC Class A，CE Class A，CCC，BIS，CB
    Environment Condition Operation: 5 ~ 40°C, 25 ~ 85% non-condensing, Storage: -40 ~ 60°C, 10 ~ 90% non-condensing
    Environmental Concern Comply with RoHS, REACH, WEEE
    Accessories • Driver and software CD
    • Quick start guide
    • USB cable
    • Power cord
